On/Off Grid Hybrid Solar Inverter 6kW | 12kW
The on/off grid hybrid solar inverter series manages PV generation and battery storage in a compatible system. Match the selected kW model to the load and battery current limits, and check the manufacturer operating modes for grid-connected and backup use. Solar self-consumption requires suitable metering and configuration. Grid export, anti-islanding approval and backup circuit design must be confirmed for the installation location. Warranty: 5 years.
List price: USD 319
Specifications
| Type | On/Off Grid Hybrid |
|---|
| Input voltage | 220/230VAC |
|---|
| Battery voltage | 48VDC (40~60V) |
|---|
| Output | Pure sine wave |
|---|
| Switching | 10ms (grid ↔ battery) |
|---|
| Efficiency | >93% |
|---|
| Communication | USB/RS485/CAN |
|---|
| Warranty | 5 years |
|---|
Models
6kW
| Power | 6200W |
|---|
| Maximum PV | 6500W |
|---|
| MPPT | 1~2 channels |
|---|
| PV voltage range | 120~500VDC |
|---|
| MPPT charging current | 100A |
|---|
| Parallel | 1~6 units |
|---|
| Protection | IP21, removable dust cover |
|---|
| Temperature | -10~50°C |
|---|
| Warranty | 5 years |
|---|
12kW
| Power | 12000W |
|---|
| Maximum PV | 13000W |
|---|
| MPPT | 2 channels |
|---|
| PV voltage range | 120~500VDC |
|---|
| MPPT charging current | 150A |
|---|
| Parallel | 1~6 units |
|---|
| Protection | IP21 |
|---|
| Temperature | -10~50°C |
|---|
| Warranty | 5 years |
|---|
Notes
- Flexible On/Off Grid switching 10ms
- Parallel 1-6 units, expandable up to 72kW
- Removable dust cover IP21
- Remote monitoring via WiFi
- Compatible with 48V LiFePO4 batteries
