Batelithium
12.8V 100Ah LiFePO4 Battery for Solar Storage
This 12.8V 100Ah LiFePO4 battery stores 1.28kWh of nominal energy for small solar storage and DC backup loads. Size the system from load current and required running time, allowing for conversion losses and the permitted depth of discharge. Check the LiFePO4 charger settings, BMS current limit and installation temperature before choosing a battery; terminal voltage alone does not establish compatibility. Warranty: 3 years · 3000 cycles.
List price: USD 156
Specifications
| Nominal voltage | 12.8V |
|---|---|
| Capacity | 100Ah / 1280Wh |
| Battery type | LiFePO4 (3.2V 100Ah cells) |
| Dimensions | 330×173×217 mm |
| Weight | 11 kg |
| Maximum charge current | 100A |
| Maximum discharge current | 150A (5s peak) |
| Protection rating | IP65 |
| BMS | Overcharge, over-discharge, overcurrent, short circuit, temperature |
| Communication | RS485 |
| Operating temperature | Charge 0~45°C / Discharge -5~65°C |
| Warranty | 3 years |
| Charge cycles | 3000 cycles |
Notes
- Compact, portable, easy to install
- Perfect replacement for lead-acid batteries
- 3000 cycles
- Smart BMS with comprehensive protection
- IP65 waterproof and dustproof rating
