Microgrid Power Conversion System (PCS) 100kW | 125kW
This microgrid power conversion system is a conversion component for an engineered battery storage network. Match the available kW model with the battery voltage window, generator controls and EMS strategy. AC coupling, DC coupling and switching equipment must follow the approved system design. A PCS on its own does not establish seamless transfer, generator compatibility or a complete microgrid; verify the final equipment combination. Warranty: 5 years.
List price: USD 11029
Specifications
| Type | Micro-grid energy storage converter (PCS) |
|---|
| Battery voltage | HV 640~1000VDC |
|---|
| AC grid | 400V/230V 3-phase, 50/60Hz |
|---|
| Efficiency | >97.5% |
|---|
| Switching | Peripheral STS, <10ms |
|---|
| Coupling | DC coupling + AC coupling |
|---|
| Parallel | Supports multiple units in parallel |
|---|
| Communication | RS485, CAN, Modbus TCP, SCADA |
|---|
| Cooling | Forced air cooling fan |
|---|
| Protection | IP54 |
|---|
| Temperature | -30~60°C |
|---|
| Warranty | 5 years |
|---|
Models
100kW
| Power | 100kW / 100kVA |
|---|
| Maximum AC current | 150A |
|---|
| Maximum battery current | 200A |
|---|
| Off-grid power capacity | 100kVA |
|---|
| Dimensions | 600×800×1200 mm |
|---|
| Weight | 150 kg |
|---|
| Warranty | 5 years |
|---|
125kW
| Power | 125kW / 127.5kVA |
|---|
| Maximum AC current | 190A |
|---|
| Maximum battery current | 250A |
|---|
| Off-grid power capacity | 127.5kVA |
|---|
| Dimensions | 600×800×1200 mm |
|---|
| Weight | 170 kg |
|---|
| Warranty | 5 years |
|---|
Notes
- Efficiency >97.5%, supports DC + AC coupling
- Peripheral STS switching on/off grid <10ms
- Supports multiple units in parallel
- Compatible with hybrid diesel generators
- Professional remote monitoring SCADA
- Suitable for industrial, small islands, large farms
