Battery Power Conversion System (PCS) 15kW | 25kW | 30kW | 40kW | 50kW | 60kW
This battery power conversion system converts energy between a compatible DC battery bank and the AC side of an energy storage installation. Select the kW option to match load demand, then check the DC voltage window and BMS/EMS interface for that exact model. AC power rating, battery energy and PV input are separate design limits. Solar input and backup arrangements require confirmation in the project wiring diagram. Warranty: 5 years.
List price: USD 3309
Specifications
| Type | Energy storage converter (PCS) |
|---|
| Battery voltage | HV 200~850VDC |
|---|
| AC grid | 400V/230V 3-phase, 50/60Hz |
|---|
| Efficiency | >97% |
|---|
| On/off grid switching | <15ms |
|---|
| Parallel | Supports multiple units in parallel |
|---|
| Communication | RS485, CAN |
|---|
| Temperature | -30~60°C |
|---|
| Cooling | Forced air cooling fan |
|---|
| Warranty | 5 years |
|---|
Models
15kW
| Power | 15kW / 15kVA |
|---|
| Maximum AC current | 22A |
|---|
| Maximum battery current | 85A |
|---|
| Off-grid power capacity | 15kVA |
|---|
| Dimensions | 540×430×170 mm |
|---|
| Weight | 35 kg |
|---|
| Warranty | 5 years |
|---|
25kW
| Power | 25kW / 25kVA |
|---|
| Maximum AC current | 36A |
|---|
| Maximum battery current | 80A |
|---|
| Off-grid power capacity | 27.5kVA |
|---|
| Dimensions | 540×430×170 mm |
|---|
| Weight | 38 kg |
|---|
| Warranty | 5 years |
|---|
30kW
| Power | 30kW / 30kVA |
|---|
| Maximum AC current | 43.5A |
|---|
| Maximum battery current | 100A |
|---|
| Off-grid power capacity | 30kVA |
|---|
| Dimensions | 540×430×170 mm |
|---|
| Weight | 40 kg |
|---|
| Warranty | 5 years |
|---|
40kW
| Power | 40kW / 40kVA |
|---|
| Maximum AC current | 57.7A |
|---|
| Maximum battery current | 120A |
|---|
| Off-grid power capacity | 40kVA |
|---|
| MPPT | 2 channels, PV up to 40kW |
|---|
| Dimensions | 600×600×900 mm |
|---|
| Weight | 90 kg |
|---|
| Warranty | 5 years |
|---|
50kW
| Power | 50kW / 50kVA |
|---|
| Maximum AC current | 72.1A |
|---|
| Maximum battery current | 150A |
|---|
| Off-grid power capacity | 50kVA |
|---|
| MPPT | 2 channels, PV up to 50kW |
|---|
| Dimensions | 600×600×900 mm |
|---|
| Weight | 95 kg |
|---|
| Warranty | 5 years |
|---|
60kW
| Power | 60kW / 60kVA |
|---|
| Maximum AC current | 87A |
|---|
| Maximum battery current | 180A |
|---|
| Off-grid power capacity | 60kVA |
|---|
| MPPT | 2 channels, PV up to 60kW |
|---|
| Dimensions | 600×600×900 mm |
|---|
| Weight | 100 kg |
|---|
| Warranty | 5 years |
|---|
Notes
- Conversion efficiency >97%
- High voltage HV battery 200-850V, compatible with 280/314Ah cells
- 3-phase 400V, supports parallel connection of multiple units
- Fast on/off grid switching <15ms
- Supports combined operation with diesel generators
- Suitable for villas, factories, small islands, farms
